FAAC is the undisputed world leader in automated systems for opening gates, doors and
garage doors. We produce automatic movement operators for gates, garage doors, barriers,
rolling shutters, glazed doors, swing shutters, and access control systems, with countless
solutions for intensive, heavy commercial uses as well as for residential applications. FAAC's
hydraulic operators utilize modern technology assuring years of trouble-free, smooth and quiet
operation for even the largest gated communities. These operators have met rigorous UL-325
safety standard testing, thus reducing a community's liability.
garage doors. We produce automatic movement operators for gates, garage doors, barriers,
rolling shutters, glazed doors, swing shutters, and access control systems, with countless
solutions for intensive, heavy commercial uses as well as for residential applications. FAAC's
hydraulic operators utilize modern technology assuring years of trouble-free, smooth and quiet
operation for even the largest gated communities. These operators have met rigorous UL-325
safety standard testing, thus reducing a community's liability.
| FAAC 746 Commercial Slide Gate Openers FAAC MODEL 746 is designed for residential and light duty commercial applications. Available in chain and rack&pinion versions. 1/2 HP motor features Gentle Slide™ Motion Management. Model 746 has 2 year limited warranty. FAAC MODEL 746 CHAIN KITS INCLUDE: Operator, Control Panel, Sprocket Idlers and protective cover Easy install limit switch plates Mounting angle brackets chain-to-gate mounting hardware with nickel plated master links Chain is not included (Installation kits available) FAAC MODEL 746 RACK & PINION KITS INCLUDE: Operator, Control Panel, Pinion Mounting angle brackets Limit switch plates Rack is not included (Installation Kits available) Features: * 230 VAC * External limits * Manual release (non-keyed) * "Soft Stop” on opening and closing *3/4 hp motor * Oil immersed clutch which, when properly adjusted, limits the amount of pressure the operator can apply to moving the gate. * Duty Cycle: 30% motor run time Microprocessor control: * Choose from 4 operating modes: * signal to open, signal to close * automatic logic * security logic * S2 security logic |
| FAAC 746 Commercial Slide Gate Openers The FAAC 746 Compact Slide Gate Opener uses GentleSlidetm Motion Management to slide gates with a pulling force of up to 35 lb (16 kg). This gate opener is available in two basic versions, the rack and pinion or the chain version. It comes as a package containing the drive unit and factory-wired electronic control panel inside the top cover of the unit. All external reversing devices and other accessories must be ordered separately. The advanced design of the operator features a small, self-contained unit composed of an electric motor with a built-in clutch and a reduction gear box, both housed in a die-cast aluminum casing. The rack or chain is driven by the motor to slide the gate. The FAAC 746 MPS microprocessor control panel is used with the FAAC 746 Slide Gate Operator. The control panel operates the slide gate according to the DIP switch settings you make for the following: • Operating logic (choose 1 of 4) • Pause time (5 sec to 2 min) • 5-sec preflashing of an attached warning light. The control panel provides power for gate accessories of 24 VDC (pulsed or constant). The maximum recommended amperage draw for accessories should not exceed 360 milliamps. An adjustable friction clutch is located on the input side of the gear box so that when torque exceeds a preset value, the drive torque on the output shaft remains at a constant level. The 746 operator is also equipped with an electronic speed sensor control device that is designed to help provide anti-crush protection |
