FAAC is the undisputed world leader in automated systems for opening gates, doors and
garage doors. We produce automatic movement operators for gates, garage doors, barriers,
rolling shutters, glazed doors, swing shutters, and access control systems, with countless
solutions for intensive, heavy commercial uses as well as for residential applications. FAAC's
hydraulic operators utilize modern technology assuring years of trouble-free, smooth and quiet
operation for even the largest gated communities. These operators have met rigorous UL-325
safety standard testing, thus reducing a community's liability.
garage doors. We produce automatic movement operators for gates, garage doors, barriers,
rolling shutters, glazed doors, swing shutters, and access control systems, with countless
solutions for intensive, heavy commercial uses as well as for residential applications. FAAC's
hydraulic operators utilize modern technology assuring years of trouble-free, smooth and quiet
operation for even the largest gated communities. These operators have met rigorous UL-325
safety standard testing, thus reducing a community's liability.
| FAAC 400 Heavy Duty Hydraulic Swing Residential or Commercial Gate Opener Model 400 Kit includes: * One hydraulic gate opener with mounting hardware * One 455 D control panel * One 14 x 16 in. weather resistant, pre-wired, UL Listed fiberglass enclosure * One manual release key . 115 VAC receptacle for accessories (5 amp max.) * ON/OFF switch controlling power to control panel, accessories and plug outlet * Large pre-wired terminals for easy wiring to control panel * Test button * Two warning signs |
| FAAC 400 Heavy Duty Hydraulic Swing Residential or Commercial Gate Opener The Model 400 hydraulic swing gate opener is specifically designed for situations needing maximum versatility, such as certain apartment, subdivision, commercial/industrial and residential applications. It's strength also makes the 400 an excellent choice for large, ornate gates. Hydraulic swing gate operators are inherently safer than other types of operators because they do not have "pinch points." In addition, FAAC operators are equipped with a hydraulic bypass valve for extra anti-entrapment protection, and a manual release that allows the gate to be operated in an emergency, such as power failure. A battery back-up unit is also available. The 400 hydraulic system can hydraulically lock your gate in your choice of the opened and/or closed positions. Your gate system will also be set up to provide special options, including "gate-safe" and "gate-secure" configurations: * Gate-safe: during power outages, a magnetic lock releases a closed gate to permit emergency access. * Gate-secure: during power outages, an electric lock keeps a closed gate locked. The versatile FAAC control panel allows for six operating modes including garage-door-like operation, and a new HOLD OPEN function. The 400 can be mounted inside the gate and still allow the gate to open to the inside or to the outside. |
Spec Sheet Manual Manual
450 MPS Control Panel Installation Manual
455 MPS Control Panel Installation Manual
450 MPS Control Panel Installation Manual
455 MPS Control Panel Installation Manual
| FAAC 400 Heavy Duty Hydraulic Swing Residential or Commercial Gate Opener The FAAC 400 Swing Operator is an automatic residential gate opener for a swinging gate leaf. It can accommodate a gate leaf of up to 2000 lb (900 kg) and up to 20 ft (6 m) in length. The self-contained 400 commercial Operator is an electro-hydraulic unit consisting of an electric motor, a pump, a valve assembly, and a hydraulic cylinder, all housed in an anodized aluminum oil reservoir. FAAC 400 Swing Gate Operator can be used to swing the gate leaf inward or outward. Most versions provide hydraulic locking in at least one position, either opened or closed, depending on how it was ordered. The hydraulic lock is a service device rather than a security device. Additional, external locks are recommended under the following conditions: * You are installing the Model 400 SB * The length of the gate leaf is 12 ft or more * The installation requires tight security * The site is subject to vandalism * The site is subject to strong or very gusty wind * You are installing a solid face gate. All FAAC 400 kits include a Model 455 D control panel. One 455 D operates single leaf or bi-parting gates Provides opening and closing "slow down, soft stop" convenience Easy interconnection of loop detectors, photobeams, etc. to reverse a gate if an obstacle is sensed Easy interconnection of actuating devices like remote control radios, key pads and telephone entry systems On board programming via push button Panel also allows for the use of FAAC Gate Coders, for “real time” tracking of gate position Selectable logics: A (automatic): signal to open, gate closes automatically after selected timed pause S (security): similar to A logic, useful in reducing tailgating E (semi-automatic): garage door-like operation; signal to open, signal to close EP (semi-automatic): similar to E logic, but second signal stops gate, third signal reverses gate B (manned, pulsed): designed for guard station use, requires 3-button switch (pulsed) to open, close and stop gate C (manned, constant): similar to B logic, but 3-button switch requires constant pressure on each button |
| The FAAC 400 is quiet, yet powerful hydraulic produce smooth and safe gate operation. It’s compact size enhances gate design. The Model 400 can handle a gate leaf up to 23 feet |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
