FAAC is the undisputed world leader in automated systems for opening gates, doors and
garage doors. We produce automatic movement operators for gates, garage doors, barriers,
rolling shutters, glazed doors, swing shutters, and access control systems, with countless
solutions for intensive, heavy commercial uses as well as for residential applications. FAAC's
hydraulic operators utilize modern technology assuring years of trouble-free, smooth and quiet
operation for even the largest gated communities. These operators have met rigorous UL-325
safety standard testing, thus reducing a community's liability.
garage doors. We produce automatic movement operators for gates, garage doors, barriers,
rolling shutters, glazed doors, swing shutters, and access control systems, with countless
solutions for intensive, heavy commercial uses as well as for residential applications. FAAC's
hydraulic operators utilize modern technology assuring years of trouble-free, smooth and quiet
operation for even the largest gated communities. These operators have met rigorous UL-325
safety standard testing, thus reducing a community's liability.
| FAAC 390 Low Voltage Electro-Mechanical Swing Gate Operators FAAC 390 24v Operator is an automatic swing gate operator for a residential swinging gate leaf that is ideal for large columns. The self- contained 390 24v swing Operator consists of a irreversible electromechanical motor and articulated arm. The locking the 390 24v swing gate Operator provides in the fully opened and fully closed positions is a service device rather than a security device. Additional, external locks are recommended under the following conditions: ∗ It is a solid-faced gate. ∗ The length of the gate leaf is 6 ft (2 m) or longer. ∗ The installation requires tight security. ∗ The site is subject to vandalism. ∗ The site is subject to strong or very gusty wind In two-operator gate installations, both (master/slave) operators are wired to one control panel. The electronic control panel is a microprocessor-based controller that accepts a wide range of product accessories and reversing devices, thus allowing for flexible gate system design |
| FAAC 390 Features Include: * Perfect for existing large gate pillars * No gate modifications are necessary * Easy installation * Reverse on contact * One plug-in radio receiver * Slow down “soft stop” * Battery back-up FAAC 390 Kits Include: * One gate operator with mounting hardware * One programmable control panel that operates single leaf or bi-parting gates * One 14 x 16 in. weather resistant, UL Listed, fiberglass enclosure * Two batteries and transformer * Warning signs |
| FAAC 390 Swing Gate Operators Applications: Single family residence, single leaf or bi-parting gate (vehicles only, not for pedestrian use) Duty cycle: 100% Maximum gate swing 120 degrees 90 degree opening time 13 seconds Maximum . weight per gate leaf 400 pounds (181.4 kg) Maximum length per gate leaf 10 feet (3 m) Approx. operating temperature range -4°F to131°F (-20°C to 5°C) Voltage Primary: 115 VAC Secondary: 24 VDC (100va transformer) Absorbed power 40 W Current 2 A Protection class Nema 4x Batteries (2 required) 7.5 amp hour, 12v |
