American Access System Phone Link 16-2050
AAS PhoneLink telephone entry system is constructed using a heavy gauge, powder coated enclosure and
stainless steel faceplate and is designed to be either post or surface mounted. This system features a “one-
shot” code, which enables the user to safely give out a code for one time use only. Additional features
include call waiting, call forwarding, full programming capability from the interior telephone, a manual
override providing phone switching in the event of damage to the telephone entry unit and an optional
pinhole camera for additional security
|
|
|
American Access System Phone Aire 16-1050t & 16-1050r
AAS PhoneAire is a fully digital, wireless telephone entry system. The transmitter is constructed using a
heavy gauge, powder coated enclosure and stainless steel faceplate that mounts directly to a pedestal or
can be surface mounted. The
PhoneAire’s receiver is mounted in a standard rain-tight enclosure with a baked enamel finish and mounts
directly to the side of the home or main building. This system features call forwarding, call waiting, “one-
shot” code, sleep mode, full
programming capability from the interior telephone, a manual override providing phone switching in the
event of damage to the telephone entry unit. For pre-authorized entry, a fully programmable 500 code
keypad is provided
|
|
|
American Access System AdvantageDKLP 19-50,19-50i,19-50sg
The AdvantageDKLP line of keyless entry offers a wide selection of post or surface mount models and
allows integration with an intercom. All post mount units are housed in heavy metal, powder coated
enclosures with metal keypad. Also available in the AdvantageDKLP line of keypads is a surface mount
“single gang” model, designed for indoor use.
Introduced for the solar gate operator, the DKLP series is designed for the user who has need for a LOW
POWER application. Boasting a power consumption of under 20uA, the AdvantageDKLP line of keypads is
the leader in the industry for solar applications. Available in 50 code configurations. Non-volatile memory is
standard.
|
|
|
American Access System DKLP 19-50I
Code Capacity: 10 Programmable Personal Master Code
Variable Relay Output
Time - 1 - 9 seconds
Optional Camera (available in intercom models only)
Audible Tone
Non-Volatile memory
Power Consumption: 20uA @ 12VDC in idle mode
|
|
|
American Access System DKLP 19-50g
Code Capacity: 10 Programmable Personal Master Code
Variable Relay Output
Time - 1 - 9 seconds
Audible Tone
Non-Volatile memory
Power Consumption: 20uA @ 12VDC in idle mode
|
|
|
American Access System AdvantageDKE 26-100L & 26-100sg
The AdvantageDKE line of digital keyless entry offers both post or single gang, surface mount
configurations. All models are stand alone and have 100 fully programmable, four digit codes.
AdvantageDKE post mount models are housed in heavy metal, powder coated enclosures with stainless
steel faceplates. A metal keypad is used providing years of trouble free use. With a 100 code capacity, the
26-100L and the 26-100sg keypads are the perfect solution for many low cost installations.
|
|
|
American Access System AdvantageDKE 26-100L & 26-100sg
The AdvantageDKE line of digital keyless entry offers both post or single gang, surface mount
configurations. All models are stand alone and have 100 fully programmable, four digit codes.
AdvantageDKE post mount models are housed in heavy metal, powder coated enclosures with stainless
steel faceplates. A metal keypad is used providing years of trouble free use. With a 100 code capacity, the
26-100L and the 26-100sg keypads are the perfect solution for many low cost installations.
|
|
|
American Access System AdvantageDK II 24-1000, 24-1000i, & 24-1000d
Available with 1000, five digit code configurations, the AAS AdvantageDKS II is one of the most cost
effective, non PC based keypad controllers on the market. Each master controller is designed to operate
two 26 bit, wiegand output keypads (see the AAS RemotePro KP line), where all programming and auditing
is done from the master station. The AdvantageDKS II master controllers are available in two
configurations: post mount or desk cabinet. Post mount masters (also available with intercom capability)
are housed in heavy metal, powder coated enclosures with stainless steel faceplates and metal keypads.
The desk cabinet (interior use only) is enclosed in a black metal housing. Each AdvantageDKS II master
station allows the user to randomly generate up to 1000, five digit codes and automatically enter them into
memory.
|
|
|
American Access System Advantage DK II 24-1000, 24-1000I, 24-1000D
Programmable five digit codes: 2000 code capacity
Two slave keypad ports, 26 bit wiegand (see RemotePro KP)
Programmable Personal Master Code, Latch Code and Sleep Code
Split Relay Function allows activation of two separate doors / gates
Optional Camera (intercom model only)
3 strikes you're out
True Anti Pass Back
1000 code transaction buffer
|
|
|
American Access System Advantage DK II 24-1000, 24-1000I, 24-1000D
Each AdvantageDKS II master station allows the user to randomly generate up to 2000, five digit codes and
automatically enter them into memory. These codes can be printed out using an RS-232 serial port printer
(see Printers). The controller will also report time, date, code number entered, relay activated and
valid/invalid code
|
|
|
American Access System AdvantageDK ADV-1000 & ADV-1000i
The AdvantageDK line of keyless entry offers a selection of post mount models and is available with call
button and durable 8 ohm speaker allowing integration with an built-in intercom station. AdvantageDK
models are stand alone and fully programmable from the keypad. Post mount models feature a high grade,
stainless steel faceplate and metal keypad and are housed in a heavy metal, powder coated enclosure
which will provide years of trouble free entry. The AdvantageDK line of keyless entry has the right product
for many different applications. The ADV-1000 features a lighted panel (post mount only) with 1,000 fully
programmable, totally independent codes. It also provides a programmable latch code and sleep code with
3 strikes you’re out security, 2 relays and an external event input.
|
|
|
American Access System AdvantageDK, ADV-1000 & ADV-1000I
Programmable four digit codes: 1000 Code Capacity
Programmable Personal Master Code
Programmable Latch Code
Programmable Sleep Code
3 strikes you're out
External event input
Two relays w/ variable relay output time: 1 - 99 seconds
LED indicators and Night Light
Optional camera (intercom model only)
|
|
American Access System 19
|
|
|
|
 |
|
|
American Access System AdvantageDKW, 19-100W
The Advantage DKW Wireless entry keypad is available in a post mount model and is housed in a heavy
metal, powder coated enclosure with a metal keypad. The AdvantageDKW has a 100-four digit code
capacity and non-volatile memory is standard. AAS has manufactured the AdvantageDKW series for the
user who has the need for a high quality, durable, wireless keypad using a 300MHz transmitter to match the
standard 300mHz frequency receiver installed for remote receiver in the gate operator. A separate weather
tight receiver is available where the existing receiver is not provided, or if the existing receiver is not a
300MHz frequency receiver. The AdvantageDKW receiver is housed in a weather tight enclosure for
mounting “outside” of the gate operator. With up to 50 feet of “keypad to receiver” frequency range, the
AdvantageDKW is perfect when trenching across a driveway, or wiring to the gate operator is not
permitted. It is the best low cost, fast installation, high quality solution for any wireless keypad application.
|
|
American Access System 23-206
|
|
|
|
 |
|
|
American Access System Stan Alone Proximity Card Reader 23-206 & 23-206I
All StandAlone Proximity card readers have a 1000 memory transaction buffer that can be printed out on an
RS-232 serial printer (see Printers). The unit will report date, time, card number entered, relay activated and
valid / invalid cards. When two card readers (such as an entry / exit application) are required, choose model
# 23-206. This unit allows an additional proximity reader (see RemotePro CR) to be wired to it, making it
ideal for jobs where more than one reader is needed.
The AAS line of StandAlone Proximity card readers combine the latest in proximity technology with the ease
of non-PC programming.
2000 card capacity
Programmable Master Card, Latch Card and Sleep Card
3 Strikes you're out and True Anti Pass-back
Optional camera
|
|
American Access System 23-206I
|
|
|
|
 |
|
|
American Access System Stan Alone Proximity Card Reader 23-206 & 23-206I
Each StandAlone Proximity card reader features a high grade stainless steel faceplate with heavy metal,
powder coated enclosure. Mounted to the faceplate is either a Secura Key RK reader, or an HID Prox Point
reader, with the control board mounted safely inside the rugged enclosure. To program the unit, simply
unlock the faceplate and use the enclosed keypad to enter codes.That's it!
Maximum number of stations per cable 4
Maximum number of stations per system 20
|
|
American Access System 23-206S
|
|
|
|
|
|
|
American Access System Stan Alone Proximity Card Reader 23-206 & 23-206I
All StandAlone Proximity card readers have a 1000 memory transaction buffer that can be printed out on an
RS-232 serial printer (see Printers). The unit will report date, time, card number entered, relay activated and
valid / invalid cards. When two card readers (such as an entry / exit application) are required, choose model
# 23-206s, This unit allows an additional "slave" proximity reader (see RemotePro CR) to be wired to it,
making it ideal for jobs where more than one reader is needed.
2000 card capacity
Programmable Master Card, Latch Card and Sleep Card
3 Strikes you're out and True Anti Pass-back
Optional camera
|
|
AAS 11- 3500 & 11-3500Slave
|
|
|
|
AAS Stand Alone Touch Plate Card Reader 11-3500, 11-65000, 11-3500S,
11-6500s
The AAS line of StandAlone Touch Plate card readers combine the latest in touch plate technology with the
option of PC or non-PC programming. The surface mount readers are constructed of durable Lexan
material for years of trouble free entry. There are two models of StandAlone Touch Plate to choose from:
the 11-3500smp which has no PC programming, audit trail or remote slave capability, or the 11-65000smp,
which features all three of these options. Both models are stand alone units, which mean they don't require
an additional controller.
|
AAS 11- 65000 & 11-65000Slave
|
|
|
|
 |
|
|
|
|
|
Programmable Latch Card
Programmable Sleep Card
Timed Anti Pass-back
3 strikes you're out
Non-volatile memory
15 Time Zones / 32 Holidays (11-65000 only)
5,000 memory transaction buffer (11-65000 only)
500 Limited use cards (11-65000 only)
3 Auxiliary Inputs: user defined (11-65000 only)
Automatic Daylight Savings Time (11-65000 only)
Modem / Network compatible (11-65000 only)
|
|
AAS Stand Alone Touch Plate Card Reader 11-3500, 11-65000, 11-3500S,
11-6500s
The AAS line of StandAlone Touch Plate card readers combine the latest in touch plate technology with the
option of PC or non-PC programming. The surface mount readers are constructed of durable Lexan
material for years of trouble free entry. There are two models of StandAlone Touch Plate to choose from:
the 11-3500smp which has no PC programming, audit trail or remote slave capability, or the 11-65000smp,
which features all three of these options. Both models are stand alone units, which mean they don't require
an additional controller.
|
|
American Access System 11-024
|
|
|
 |
|
|
American Access System Mechanical Card Reader 11-024 or 11-024i
When price and ease of use are important, the American Access Systems, Inc. line of StandAlone
Mechanical card readers fits the bill. With no power or programming required, this is one of the simplest
card readers available today! Each StandAlone Mechanical card reader features a high grade stainless
steel faceplate with a heavy metal, powder coated enclosure. To use, simply unlock the faceplate and
install the program cartridge. Then, when a card is inserted into the slot, the relay will close and the gate /
door will open. That's it. It's that simple!
|
|
American Access System 11-024I
|
|
|
|
 |
|
|
American Access System Mechanical Card Reader 11-024 or 11-024i
Since there is no programming required, an unlimited amount of cards may be used with each reader,
making this a perfect solution for a low cost / low security application! Unlimited card capacity
No power required
12VAC night light is included
Limited two year warranty
Optional Intercom available
Optional Camera available (intercom model only)
|
Intercom inside station
|
|
|
 |
|
|
|
Intercom Inside Ststion.
The AAS exterior post mount intercom station will interface with almost any brand of interior, master
station currently sold in the US. This outside intercom station is available as a stand alone unit when no
keypad or card reader is needed. Each exterior station is constructed using a heavy duty, powder coated
metal enclosure with stainless steel faceplate. An 8 ohm mylar speaker and weather resistant call button
are also included in each unit.
AAS is also proud to make available the AiPhone line of interior master stations.These high quality units will
interface directly to any intercom station that AAS manufactures. The Aiphone models can be mounted
directly to the wall or mounted on a desk. Each inside station also includes a release button to activate the
relay and open the gate or door where the exterior intercom station is located. All AiPhone equipment sold
by AAS is for interior use only!
These systems allow for a range of 1500 feet and the ability to wire up to several interior stations to one
system.
|
