| Viking Q-4 Slide Gate Operator CLASS II, CLASS III, CLASS IV VEHICULAR GATE OPERATOR |
| Viking Q-4 Slide Gate Openers / Gate Operators - The Q-4 incorporates a powerful and efficient DC motor, a high ampacity power supply, an integrated battery back-up system and intelligent controller. The incorporation of these features results in outstanding performance on heavy duty slide gates. The advanced motor control circuit driving the motor guarantees long life. The Q-4 brings the advantages of DC gate operators into heavy duty applications. |
| Operation 24 VDC Main Power Source 120 / 220 VAC Single Phase Battery(optional) 33 to 100 AmpHr 12 VDC x 2 Max Gate Weight 4000 lbs. Max Gate Length 80 Feet Max Operating Speed up to 16" per second Battery Backup Operation 100 Full Cycles (2000 lbs. / 40' gate) Max Duty Cycle 100% (Continuous Cycles) Operating Temperature -4°F to +158°F |
Manuals PDF
| Viking Q-4 Gate Operators / Slide Gate Operators - Some of the standard features include: 5 year commercial warranty, UL 325 and 991 listing, innovative fine tune adjustment for the end of gate travel ( down to 1/8" ), adaptive algorithm with smooth acceleration and deceleration, more than 1/2 kilowatt of power, built in battery backup capable of 100 cycles in case of power failure, a powerful and effecient gear head motor, fail-safe - fail-secure electromechanical lock, and adjustable height for the main drive. |
| CLICK HERE TO PURCHASE OR VIEW COMPLETE SELECTION OF VIKING ACCESS GATE OPENERS AND ACCESSORIES |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| L. A. Ornamental & Rack Corp 3708 NW 82nd Street Miami, Florida 33147 Office: 305-696-0419 Fax: 305-696-0419 |
