|PowerMaster BSG Gate Openers Specifications:
Supply Model BSG Slide Gate Operator, as recommended for cantilever, rolling, or overhead suspended sliding gates. The operator shall have a
heavy duty timing belt primary reduction. The secondary reduction shall consist of heavy duty roller chain and solid steel chain sprockets. The final
drive shall consist of solid steel drive sprockets and #41 roller chain (included). The limit switches shall be rotary chain driven type, adjusting
without tools. The drive shafts shall be a minimum of 1" diameter steel supported by roller bearings. An adjustable torque limiting clutch shall be
provided to prevent overload damage to operator. A spring set, solenoid released, double shoe brake shall be provided to prevent gate from
Motor to be high starting torque, industrial type, removable without affecting limit switch settings, and shall incorporate thermal overload protection.
The motor controller shall be a full voltage, across-the-line, mechanically interlocked reversing contactor.
The Control circuit shall be 24 VAC and shall include a maximum run timer to limit run time to 90 seconds or less, a 1.5 second delay on reverse to
reduce shock loads on gate and provisions for all types of obstruction sensing devices. A clearly marked, thermal strip shall be provided for all field
connections. The control shall have provisions for connecting; 3 button stations, single button stations, radio controls, loop detectors and automatic
closing timer without additional changes.
The operator must be field convertible from right hand to left hand and for use as a single, master or slave without additional parts or modifications.
An on/off switch will be provided to disconnect power at electrical enclosure. The operator stand shall be heavy gauge steel, primed and painted to
resist corrosion with provisions for mounting to concrete pad.
The weather proof cover shall have a lockable hinged cover for access to control equipment.
PowerMaster BSG Gate Openers Electrical Specifications:
High Starting Torque Motor
Full Overload Protections
24 VAC Control Circuit
Heavy Duty, Full Voltage, Reversing Contactor
3 Button NEMA 1 Control Station Included
On/Off Power Switch
Left/Right Direction Plug
Pre-wired to Accept Radio Control, 3 Button Station, 1 Button station, Loop Detectors, Automatic Reversing Equipment, and all types of Access
Easily Field Converted to Master/Slave (Two Operators Required)
Delay on Reverse
Maximum Run Timer
PowerMaster BSG Gate Operators Mechanical Specifications:
For Use on Medium Duty Commercial or Industrial Slide Gates (Up to 35' Wide or 1000 lbs. Max.)
timing belt and pulleys for quiet operation
Chain and Sprocket Final Reduction
Positive Chain Driver Rotary Limit Switches
Gate Driven by #41 heavy Duty Roller Chain, Included
1" Drive Shaft Supported by Roller Bearings
Adjustable Torque Limiting Clutch
Electric Solenoid Brake
Manual Disconnect Provided
Steel, Lockable, All Weather Hinged Cover
|Power Master BSG Medium Duty Commercial Sliding Gate Operator
