| Supply Model SGI Slide Gate Operator, as recommended for cantilever, rolling, or overhead sliding gates. Operator to have oilbath type, worm gear reducer. Final reduction and drive chain to be #50 or larger roller chain. Output shafts minimum 1" diameter, supported by sealed roller bearings. Provide adjustable torque limiting clutch and solenoid operated brake. Mechanical disconnect by means of lockable handle to follow manual operation. Adjustable limit switches of the positive chain driven type. Motor to be high starting torque, continuous duty rated industrial type, protected by thermal or current sensing overload device. Motor must be easily removable without affecting limit switch settings. The motor controller shall be a full voltage, mechanically interlocked interlocked, across-the-line, reversing contactor. The Control circuit shall be 24 VAC with pre-wired terminal strips for field connections. Control circuit will provide for 3 button stations, radio controls, loop detectors, obstruction sensing devices. The control circuit will also provide for open override, 1.5 second delay on reversing and have provisions for automatic closing timer and timer defeat switch. An on/off switch will be provided to disconnect power at electrical enclosure. Slide gate operators will be adaptable to master/slave operation without any additional components. Right hand mounting is standard, field convertible to left hand mounting. Operator shall be assembled in a primed and painted 10 gauge weatherproof enclosure for mounting on concrete pad. Electrical Specifications: High Starting Torque Motor Full Overload Protections 24 VAC Control Circuit Heavy Duty, Full Voltage, Reversing Contactor 3 Button NEMA 1 control Station Included On/Off Power Switch Left/Right Direction Switch Pre-wired to Accept Radio control, 3 Button Station, 1 Button Station, Loop Detectors, Automatic Reversing Equipment, and all types of Access Controls Easily Field Converted to Master/Slave (Two Operators Required) Delay on Reverse Maximum Run Timer Mechanical Specifications: For Use on Commercial or Industrial Slide Gates (Up to 80' Wide or 2400 lbs. Max.) 45:1 Gear Reducer (Oil Bath Type) Positive Chain Driven Rotary Limit Switches Gate Driven by #50 Heavy Duty Roller Chain, Provided with Operator 1" Drive Shaft Supported by Roller Bearing Pillow Blocks Adjustable Torque Limiting Clutch Electric Solenoid Operated, Double Shoe Brake 10 Gauge Weather Proof Enclosure |
- Easily Field Converted to Master/Slave (Two
Operators Required) - Delay on Reverse Maximum Run Timer
- 45:1 Gear Reducer (Oil Bath Type)
- Positive Chain Driven
- Rotary Limit Switches
- Gate Driven by #50 Heavy Duty Roller Chain,
Provided with Operator - 1" Drive Shaft Supported by Roller Bearing
- Pillow Blocks Adjustable Torque Limiting Clutch
- Electric Solenoid Operated,
- Double Shoe Brake
- 10 Gauge Weather Proof Enclosure
