|American Access System 23-106 or 23-106i
The American Access Systems, Inc. line of StandAlone Proximity card readers combine the latest in proximity
technology with the ease of non PC programming.
Each StandAlone Proximity unit features a a high grade stainless steel faceplate with heavy metal, powder
coated enclosure. Mounted to the face plate is an HID Prox Point reader with the controller board safely
mounted inside the enclosure. Simply unlock the faceplate and program the unit from the enclosed keypad.
That’s it. It’s that simple!
All StandAlone Proximity card readers have a 1000 transaction memory buffer that can be printed out on an RS-
232 serial port printer (AAS #21-045 or #21-047). The unit will report time, date, card number entered, relay
activated and valid / invalid card.
When more than one card reader is needed at an access point, choose model #23-206(i). This unit allows an
additional “slave” proximity reader (see the AAS RemotePro CR line) to be wired to it, making it the ideal
product for an entry / exit application or where two proximity readers are needed.
Input: 16.5VAC (transformer included)
Output: n/o or n/c contact 1-99 second
Operating temperature: -15 to 175 Fahrenheit
Dimensions: 6.625h x 5.50w x 4.25d
Intercom: 8 ohm Mylar speaker w/ call button
Relay Specs DC Load AC Load
Contact Rating 1A @ 24V .5A @
Max. switching voltage 150V 220V
Max. carrying current 2A 2A
Max. switching power 28W 60VA
2000 card capability
Programmable Personal Master
Programmable Latch / Unlatch Card
Programmable Sleep Card
Three strikes – you’re out
True Anti Pass Back
1000 code transaction buffer
Limited two year warranty
