American Access Systems, Inc. has been manufacturing high quality
access control equipment for the security and installation professional.
Based in the heart of the Rocky Mountains (Centennial, CO), we have a
nationwide distribution network to provide easy access to each of our
products. We offer a wide range of access control systems, including
telephone entry, intercoms, card readers, keypads and even simple to
use multi-unit PC based systems
access control equipment for the security and installation professional.
Based in the heart of the Rocky Mountains (Centennial, CO), we have a
nationwide distribution network to provide easy access to each of our
products. We offer a wide range of access control systems, including
telephone entry, intercoms, card readers, keypads and even simple to
use multi-unit PC based systems
| American Access System Phone Link 16-2050 The American Access Systems, Inc PhoneLink telephone entry system is constructed using a heavy gauge, powder coated enclosure and stainless steel faceplate and is designed to be either post or surface mounted. Functions available with the PhoneLink allow the user to conveniently screen entrants from the security of a telephone inside the home or office. When a guest presses the call button, a double ring alerts the people inside that someone is at the gate, rather than an incoming telephone call. Access is allowed by simply pressing * * for a momentary relay operation, or * # to latch the gate open. The gate can be called and latched open without a guest being present at the gate. This system features a “one-shot” code, which enables the user to safely give out a code for one time use only. Additional features include call waiting, call forwarding, full programming capability from the interior telephone, a manual override providing phone switching in the event of damage to the telephone entry unit and an optional pinhole camera for additional security. For the guest with pre-authorized entry, a fully programmable 500 code keypad is provided. The PhoneLink telephone entry is a “No Phone Line” telephone entry system, allowing you to use your existing telephone line without creating an addition to the phone bill. |
| General Specifications Input: 12 VAC or VDC (Transformer included) Output: n/o or n/c contact 1 -99 second Operating temperature: -15 to 175 Fahrenheit Dimensions: 7 3/8” H x 7 3/8” W x 5” D 8 ohm Mylar speaker w/ call button Ship weight: 9 lbs. 3000 ft. range Less than 45 mA draw (without nightlight) Relay Specs DC Load AC Load Contact Rating 2A @ 30V .5A @ 125V Max. switching voltage 125V 125V Max. carrying current 2A 2A Max. switching power 60W 62.5VA |
| Features 500 access code capacity Programmable Personal Master Code Programmable Latch / Sleep Code Programmable “One -Shot” Code Fully programmable from telephone 2 relays Adjustable volume: - microphone, speaker & phone tone Event Input Night Light “60 second o n” capability Optional camera Unique double ring cadence Call waiting Call forwarding Call button disconnect By-pass switch included |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
| |
 |
American Access System Phone
Link 16-2050 Telephone Entry
System -- $739.00
Link 16-2050 Telephone Entry
System -- $739.00
