Viking K-2 Slide Gate Openers / Gate Operators
The K-2 slide gate operator raises the bar in quality for the residential market. This machine operates a highly efficient direct motor drive
which allows operation at 100% duty cycle. This assures efficiency and reliability. The fail-safe, fail-secure options of the K-2 gate operator
allows it to handle gates up to 650 lbs. in conformance with UL 325 and UL 991 Type I, III and IV. Operation 24 VDC with 1/2 H.P. Motor
Main Power Source 110 / 220 VAC Single Phase
Battery 7 AmpHr 12 VDC x 2
Max Gate Weight 650 lbs.
Max Gate Length 27 Feet
Max Operating Speed 12" per second
Battery Backup Operation 100 Full Cycles (650 lbs. / 20' gate)
Max Duty Cycle 100% (Continuous Cycles)
Operating Temperature -4°F to +158°F
|
|
|
PowerMaster RSG Gate Openers Architectural Specifications:
Control circuit operating voltage shall be 24 volts or less and shall provide inputs for single push button control, radio control, loop
detector, external obstruction sensing device and limit switches. Limit switches shall be directly actuated by output shaft and shall not be
affected by removal of motor or manual operation. Operator shall be easily converted to left hand or right hand gates.
Anon/off switch shall be provided in operator to disconnect unit from power source. A separate conduit box shall be provided for field
connection to power. A thermal strip shall be provided for all control connections.
- On/Off Power Switch 24 VAC Control Circuit Built-In Obstruction Sensing Device ---- Manual disconnect ---- Maximum Run Timer
- Pre wired to Accept Radio Control, Loop Detector, Photocell, 1 Button station and Key switch ---- Can be Post or Pad Mounted
- Can be Wired as Master/Slave (Two Operators Required) ---- Provided Universal Left or Right Hand
- For Use on Residential Slide Gates (Up to 14' Wide, Max. Weight 250 lbs.) ---- Mounting Steel All Weather Enclosure
- Positive Cain Driven Rotary Limit Switches
|
|
|
The Model FAAC 740 Sliding Gate opener
Combines cutting-edge technology with sophisticated styling for single family residential applications. The 740 is perfect for single family
residences: access areas of medium transit frequency. The 740 24V automated system for sliding rack pinion or chain appropriately
coupled to the gate. Can be order Rack and Pinion OR chain
FAAC 740 24V Electro Mechanical Slide gate Operator ---- Designed for residential use ---- Two year limited warranty ---- External limits
Gate automatically locks when not operating ---- Slow down "soft stop" on opening and closing ---- Convenient manual release
Operates even in case of power failure.(With optional battery back-up kit and subject to battery condition)
Specifications
Duty Cycle 100% ---- Maximum Weight per gate leaf 880 lbs. (399 kg) ----- Maximum length per gate leaf 30feet (9.1 m)
Approx. operating temperature range -4°F to 131°F (-20°C to 55°C) ---- Voltage Primary: 115vac
Secondary: 24vac(100va transformer) ----- Absorbed power/absorbed current 70W/3a
|
|
|
LIFTMASTER RSL12V DC-Powered Slide Gate Operator Battery Back up
Our most advanced residential pad mounted slide gate operator. Features a powerful DC motor with soft start/stop operation for quiet and
reliable performance and rated for gates up to 800 lbs. and 25 ft. in length and cycling up to 120 times per day. The RSL also utilizes the
Evercharge® Power Management System to provide industry leading power efficiency maximizing cycles when running on battery backup
or optional solar power.
ADDITIONAL FEATURES
Universal controller with multiple inputs ---- Timer-to-close: 0-180 seconds ---- Surge/spike protection
Dual gate compatible ---- Right- or left-handed operation ---- Ability to auto-open or failsecure when power fails/battery depletion
Heater model available ---- 3-YEAR WARRANTY
|
|
|
Liftmaster MEGA SLIDE Residential / Medium-Duty DC Slide Gate Operator
The Mega Slide is a DC-powered addition to the LiftMaster® family of slide gate operators. Designed with a 24V DC (1/2 HP equivalent)
motor, this model provides exceptional starting torque and continuous operation, making it ideal for most applications. Constructed with
an aluminum alloy chassis, it's corrosion resistant and light enough for one person to carry and install. The heavy-duty motor supports
gates weighing up to 1,000 lbs. and up to 32 ft. in length.
No power? No problem!
Built-in battery backup provides seamless operation of the gate operator and all DC control and sensing devices in the event of a power
loss.
|
|
|
RamSet 50 Residential Slide Gate Opener
This affordable gate opener features a direct-drive 1/2 horsepower motor, handling gates up to 700 lbs. The RAM 50 GB is highly
recommended for single home use for both aesthetics and its high performace. It is extremely low maintenance and is powered by our
intelligate board which offers a veriety of functions to secure your home and make your daily life a bit easier.
Max Gate Size 20' -- Max Gate Weight 700 lbs -- Ramset Model 50 UL 1/2 HP Slide Gate OperatorMotor Light Duty. 1/2 Hp, 120VAC, 50/60 hz
Dimensions H:161/2" - L:11" - W:17" Travel Speed 1' Per Second --- Shipping Weight 75lbs
• Left / Right hand Switch Adjustment ---- 3-Wire Master/Slave Synchronization Cable ---- Plug-in Loop Detector (ILD-24s)Capability
Relay Connection ---- Service Push Buttons. ----- • One pass, ERD Sensitivity Adjustments ---- Anti-tailgating. While the gate is opening,
after a safety device is detected and cleared, the gate will immediately close whether or not the limit has been reached.
When the gate is closing, if a safety is etected the gate will stop but not reverse it self. ---- • Automatic Timer
|
|
|
Electromechanical Automation For Rack Sliding Gates
SMART TECHNOLOGY
•Electromechanical microswitches that control the end of stroke. ----- •Incorporated two-channel rolling code radio receiver.
•Control unit with self-learning and self-diagnostic functions. ----- •Control unit compatible with the EELink protocol.
SAFE USE
•This version powered at 24 V has been specially designed for simpler and faster installation in compliance with latest safety standards.
•Thanks to the obstruction sensing device, the operator reverses motion and prevents damage to people and vehicles in the event of
contact.
For sliding gates up to 1100 lb (500 kg)
|
|
|
Doorking 9050 and Doorking 9070 operators
Are designed to operate vehicular slide gates in residential and light-duty commercial applications only. These operators are designed
so that they can easily be mounted in the front, center or rear of the gate without any costly and time consuming field modifications. In
addition, the operators can be pad or post mounted to meet any installation requirements.
Doorking 9050 or 9070 Residential Sliding Gate Operators / Openers
ADVANCED FEATURES
Self-adjusting, no maintenance magnetic limits. ---- Ports for plug-in loop detectors. --- Two convenience outlets.
Fail-safe release (fail-secure optional). --- Programming switches. --- Built-in reset switch. ---- Built-in power On/Off switch.
Doorking 9050 Gate Operator / Opener ---Maximum gate length 16-feet. --- Maximum gate weight 300 pounds
Doorking 9070 Gate Opener / Operator --- Maximum gate length 22-feet. ---- Maximum gate weight 500 pounds
|
|
|
Linear - OSCO SLR-211- 115 Volt Residential Slide Gate Operator
Solid State Control Circuitry: All SL series operators utilize a common UL325/UL991 compliant 24VDC control board ---- Fully featured
board for complete access control, security and entrapment protection
Polyethylene Cover: The sleek and sturdy lockable cover is available in black, tan or granite
Manual Disconnect: Secure and easy to use, allows manual operation of gate during power failure or emergencies ---- Optional remote
cable kit available for outside-the-gate access
Heavy Duty Components: Gear reducer and pillow block bearing provides smooth, reliable and quiet power transmission
Standard Convenience Features: Exterior reset button ---- Power on/off button ---- Accessory power outlet on 115V machines ----
3-button station
|
|
|
Apollo 7000 ETL Residential Slide Gate Operator
APPLICATIONS: Battery Operated, Solar or AC Charged Slide Gate Operator. Recommended for Residential, Farm and Ranch, and Light
Commercial applications. Recommended for gates up to 20 feet in length and 600 lbs. each.
OPEN OR CLOSE CYCLE TIME: Varies by gate. Operator drives gate at 1 foot per second max.
BATTERY/ CONTROL PANEL BOX: 21” (53.3cm) x 21” (53.3cm) x 8” (20cm) Powder Coated Black.
SHIPPING INFORMATION: 2 boxes, 105 lbs. (47.3 kg)
CHAIN SUPPLIED: Operator comes with 35 ft. of #40 roller chain.
NOTE: Available in Master/Slave setup
|
|
|
RSX1000 Tower Plus: 1/2 HP residential duty slide gate operator
Available in 115V and 230V supply voltage, 8.2" per second gate speed.
Ratings -- • Maximum duty cycle: 10 cycles per hour, 50 cycles per day
Features
• Steel frame -- • Architecturally designed, long-life cover -- • Overload sensing system -- • Easily adjustable limit switches
• Built-in maximum run timer -- • Adjustable auto-close timer -- • Built-in "smart" self-adjusting maximum run timer
• Built-in master/second capability -- • MVP "smart" radio receiver included -- • UL Listed for Class I, 110V only
Allstar TOWER PLUS Gate Openers Slide Gate Operator-Model RS 1000 --- Maximum Gate Length 16 Feet.
Maximum Gate Weight: 300 Pounds.
Meets the requirements of the vast majority of residential applications. An attractively styled Slide Gate Operator with all the features you
need at a price you will like.
|
|
|
Eagle One Gate Operators or Gate Openers Specifications
The Eagle-I combines smooth and quiet operation with the power and durability necessary for residential applications. The Eagle-I
Residential sliding gate operator uses the latest in technology to provide you with the safest and most efficient operator for your money
Control Board - The Unique Control Board uses state of the art technology combined with ease of use to provide many exceptional
features not found in any other board
2 Wire Maser/Slave - The board uses a unique Master/Slave system that requires only two wires.
Motor Brake - If the on position is selected, the gate will stop instantly when it reaches the limit switches. This is essential on
uphill/downhill applications and on all Fail Safe operations.
Stop-Reverse - This radio feature allows the transmitter to work as a three-button station and is useful for partial opening. The first
command opens the gate, the second stops the gate, and the third command will close the gate.
Timer - The adjustable timer can be set from 1 to 60 seconds, with a maximum run time of 60 seconds.
Overload - If the motor reaches the stall amp for 3 seconds, it will automatically shut down.
|
|
|
SEA TAURUS BOX Residential Slide Gate Operator
The Residential sliding motor you were looking • The TAURUS BOX is a residential electromechanical
sliding operator for gate up to 600 lbs.
• It is very smooth and exceptionally quiet.---- • It is a unique compact motorized gear box. ---- • Polyethylene plastic cover.
• Slow down in opening/closing with GATE series board.---- • Reverse on obstruction. ---- • Easy limit switch adjustable with screw.
• Easy manual release. ---- • Receiver included. ----- • Ball bearing wheels. ---- • Buzzer alarm. ---- • Control board: GATE 1 or SLIDE.
• Yellow zinc metal chassis will last many years. ----- • Duty Cycles*: 20 per hour.
SEA TAURUS RACK / SEA TAURUS CHAIN SMALL VERSION
RESIDENTIAL ELECTROMECHANICAL SLIDING OPERATOR FOR GAT E UP TO 600 LBS. Compliant to UL 325
The Residential slide gate operator you are looking for, Powerful, Reliable and EASY to Install.
• The TAURUS RACK is a residential electromechanical sliding operator for gate up to 600 lbs.
• It is very smooth and exceptionally quiet. ---- • It is a unique compact motorized gear box. ---- • Reverse on obstruction. ---- • Limit switch.
• Receiver included. ----- • Nice design. ----- • TAURUS CHAIN with metal support. ----- • Duty Cycles*: 20 per hour.
|
