RAMSET Gate Operators Ram 5200 - Scroll Down to View Exploded Parts View & Parts List
RAMSET Replacement Parts for your RAMSET Operators -
We Offer RAMSET Factory Direct replacement parts and New
Products for RAMSET Systems, Gate Operators, Keypad
Parts, Proximity and Multi-Tenant Access Control panels
Item    Parts  #        Description for Ram 5200 Gate Openers
1          50-007        1/4" Hot Rolled Metal Chassis
2          50-010        Control Board Box
3          50-016        Board Lexan Cover
4          50-023        Polyethylene Cover
5          50-030        Speed Reducer Size 60/30:1 Ratio
6          50-033        1/2 hp 115 VAC Electric Motor
7          50-034        3/4 hp 115 VAC Electric Motor
8          50-035        1 hp 220 VAC Electric Motor
9          50-039        20 Pin Edge Connector
10        50-045        1/2" x 10 1/2" Limit Switch Shaft
11        50-051        35 b 17 1/2" Sprocket
12        50-052        41 b 21x1" Sprocket
13        50-055        35 b 17x1" Sprocket
14        50-058        3 1/2" UHMW Idler Pulley
15        50-059        6202-2rs Ball Bearing
16        50-061        1/2" Shaft Collar
17        50-063        Spring Load Bracket
18        50-064        3/4" Tension Spring
19        50-066        Limit Switch Nuts
20        50-069        Limit Switch 00h-3
21        50-071        5/8" x 2 1/2" Cast Iron Pulley
22        50-072        3/4" x 2 1/2" Cast Iron Pulley
23        50-077        4L "V" Belt #210
24        50-085        #35 Limit Switch Chain
25        50-088        #40 x 20' Gate Chain
26        50-089        3/8" x 2" x 7" Chain Bracket
27        50-090        1/2" x 4" Chain Bolt
28        50-091        #6 x 1" Machine Screw
29        50-092        3/8"-16 x 1 1/4" Hex Head Bolt
30        50-095        5/16"-18 Unc x 3/4" Hex Head Bolt
31        50-096        5/16" Lock Washer
Item    Parts  #        Description for Ram 5200 Gate OpenersItem
   Parts  #        Description for Ram 5200 Gate Openers
32        50-097        5/16" Flat Washer
33        50-098        5/8"-11 x 3 1/2" Hex Head Bolt
34        50-099        5/8" Flat Washer
35        50-101        3/8" Lock Washer
36        50-103        3/8" Hex Head Nut
37        50-104        5/16"-18 Hex Head Nut
38        50-105        #6 Hex Head Nut 6 6 6
39        50-106        5/8" Hex Head Nut
40        50-107        #6 x 3/8" Machine Screw
41        50-108        1/4" Flat Fender Washer
42        50-113        1/2" Hex Head Nut
43        50-151        Warning Sign for Gate
44        50-157        Instruction Manual
45        50-168        Horn Alarm
46        50-215        Rocker Switch
47        50-264         1/4" x 1 1/2" Key Way
48        50-265         3/16" x 3/4" Key Way
49        50-295         #8 Self-Tap Sheet Metal Screw
50        50-299         Radio Receiver Terminal
51        50-304         120/240 Intelligate Transformer
52        50-510         Outlet Switch Cover
53        50-511         120 VAC Double Outlet
54        50-539         5/16" Socket Head Screw
55        50-547         1/4" Hex Bolt
56        50-548         3/16" x 3/8" Socket Head Screw
57        50-549         5/8" ID x 1 3/4" Bushing
58        50-767         Chain Release
59        50-768         1/2" Bolt Release
60        50-777         Intelligate Control Board
About Us  |   Contact Us   |   Our Policies   |   FAQ   |   Manufactures   |   Links   |
Copyright Protected 2004-2008 - L. A. Ornamental & Rack Corp.  All rights reserved. No part of this site can be reproduced in any form
or by any means, electronic, mechanical, photocopying, or otherwise without prior written consent of L. A. Ornamental & Rack Corp.
3708 NW 82nd Street  Miami  Florida  33147, Office: 305-696-0419  Fax: 305-696-0461 E-Mail: LAOrnamental@Aol.com
Keypads & Telephone Entry Systems
Gate Operator Circuit Boards
Remote Controls
Loop Detectors & Safety Equipment
Receivers
Item
 Description
 Part Number
 Price
1
 1/4" Hot Rolled
Metal Chassis
 50-007
2
 Control Board Box
 50-010
3
 Board Lexan Cover
 50-016
4
 Polyethylene Cover
 50-023
5
 Speed Reducer
Size 60/30:1 Ratio
 50-030
8
 1 hp 220 VAC
Electric Motor
 50-035
9
 20 Pin Edge
Connector
 50-039
10
 1/2" x 10 1/2" Limit
Switch Shaft
 50-045
11
 35 b 17 1/2"
Sprocket
 50-051
12
 41 b 21x1"
Sprocket
 50-052
13
 35 b 17x1"
Sprocket
 50-055
14
 3 1/2" UHMW Idler
Pulley
 50-058
15
 6202-2rs Ball
Bearing
 50-059
16
 1/2" Shaft Collar
 50-061
17
 Spring Load
Bracket
 50-063
18
 3/4" Tension Spring
 50-064
19
 Limit Switch Nuts
 50-066
20
 Limit Switch 00h-3
 50-069
21
 5/8" x 2 1/2" Cast
Iron Pulley
 50-071
22
 3/4" x 2 1/2" Cast
Iron Pulley
 50-072
23
 4L "V" Belt #210
 50-077
24
 #35 Limit Switch
Chain
 50-085
25
 #40 x 20' Gate
Chain
 50-088
26
 3/8" x 2" x 7"
Chain Bracket
 50-089
27
 1/2" x 4" Chain Bolt
 50-090
28
 #6 x 1" Machine
Screw
 50-091
29
 3/8"-16 x 1 1/4"
Hex Head Bolt
 50-092
30
 5/16"-18 Unc x
3/4" Hex Head Bolt
 50-095
31
 5/16" Lock Washer
 50-096
Item
 Description
 Part Number
 Price
32
 5/16" Flat Washer
 50-097
33
 5/8"-11 x 3 1/2" Hex
Head Bolt
 50-098
34
 5/8" Flat Washer
 50-099
35
 3/8" Lock Washer
 50-101
36
 3/8" Hex Head Nut
 50-103
37
 5/16"-18 Hex Head
Nut
 50-104
38
 #6 Hex Head Nut
 50-105
39
 5/8" Hex Head Nut
 50-106
40
 #6 x 3/8" Machine
Screw
 50-107
41
 1/4" Flat Fender
Washer
 50-108
42
 1/2" Hex Head Nut
 50-113
43
 Warning Sign for
Gate
 50-151
44
 Instruction Manual
 50-157
45
 Horn Alarm
 50-168
46
 Rocker Switch
 50-215
47
 1/4" x 1 1/2" Key
Way
 50-264
48
 3/16" x 3/4" Key Way
 50-265
49
 #8 Self-Tap Sheet
Metal Screw
 50-295
50
 Radio Receiver
Terminal
 50-299
51
 120/240 Intelligate
Transformer
 50-304
52
 Outlet Switch Cover
 50-510
53
 120 VAC Double
Outlet
 50-511
54
 5/16" Socket Head
Screw
 50-539
55
 1/4" Hex Bolt
 50-547
56
 3/16" x 3/8" Socket
Head Screw
 50-548
57
 5/8" ID x 1 3/4"
Bushing
 50-549
58
 Chain Release
 50-767
59
 1/2" Bolt Release
 50-768
60
 Intelligate Control
Board
 50-777
