| FAAC Gate Operators 760 - Scroll Down to View Exploded Parts View, Parts list Click on image to enlarge |
| FAAC Replacement Parts for your FAAC Operators - We Offer FAAC Factory Direct replacement parts and New Products for FAAC Systems |
|
| About Us | Contact Us | Our Policies | FAQ | Manufactures | Links | Copyright Protected 2004-2008 - L. A. Ornamental & Rack Corp. All rights reserved. No part of this site can be reproduced in any form or by any means, electronic, mechanical, photocopying, or otherwise without prior written consent of L. A. Ornamental & Rack Corp. 3708 NW 82nd Street Miami Florida 33147, Office: 305-696-0419 Fax: 305-696-0461 E-Mail: LAOrnamental@Aol.com |
| POS PART NO. DESCRIPTION 30 N/A O-Ring (flange) 31 7366135 Cylinder 32 7099585 Gasket (cylinder) 33 7350275 Ramping Piston 34 N/A O-Ring (ramping piston) 35 7246025 Zert Fitting 36 7110045 Debris Cover 37 N/A O-Ring (manual release) 38 N/A Allen Head Bolt (piston) 39 N/A Lock Washer 40 7094115 Piston (red internal) 41 7092025 Piston Seal 42 7350275 Piston 43 7049195 Piston Seal (inner) 44 7119485 Vibration Dampener 45 N/A Lock Washer (coated) 46 N/A O-Ring (rack) 47 7193205 Rack 48 7160505 Ram Body 49 499761 Flange (non manifold) 50 N/A Allen Head Screw 51 7224215 Bracket (pump to drive) 52 7099575 Gasket (drive to box) 53 N/A Self Taping Screw 54 7276015 Rack Protecting Cover 55 7090665 O-Ring (retracting tube) 56 3905515 Skin Pack (mounting hardware) 57 2176* Seal Kit 58 6105* 1 Qt Monolec Oil ∗ Included in Kit #2167A* ∗ * 220V 1400RPM Motor Part #77000415 |
| POS PART NO. DESCRIPTION 1 7019345 Mounting Bolt (bottom) 2 7011345 Mounting Bolt (top) 3 7014801 Stainless Steel Screw (doghouse) 4 7201295 Manual Release Housing 5 4246385 Manual Release Rod 6 N/A Snap Ring 7 N/A Manual Release Rod End 8 N/A Retaining Pin 9 4180295 Manual Release 10 7099595 Gasket (manifold) 11 N/A Parallel Pin 12 499762 Manifold 13 7039285 Copper Washer 14 71101115 Banjo Bolt 15 N/A Lock Washer 16 N/A Allen Head Bolt 17 N/A O-Ring (with part No. 18) 18 4180265 Brass ByPass Cap (break) 19 7090010015 O-Ring 20 7011355 Flange Bolt (10 x 150mm) 21 N/A Lock Washer 22 N/A Jack Counter Nut Brass Jam Nut 23 N/A Snap Ring 24 499760 Flange (manifold side) 25 7361365 Retract Tube 26 N/A Allen Head Screw 27 N/A O-Ring (with part No. 28) 28 4404085 Lock Valve 29 N/A Snap Ring |
| Item | Description | Part Number | Price |
| 1 | Mounting Bolt (Bottom) | 7019345 | Our Price: $17.00  |
| 2 | Mounting Bolt (Top) | 7011345 | Our Price: $6.00 |
| 3 | Stainless Steel Screw (Doghouse) | N/A | |
| 4 | Manual Release Housing | 7201295 | Our Price: $13.00 |
| 5 | Manual Release Rod | 4246385 | Our Price: $37.00 |
| 6 | Snap Ring | N/A | |
| 7 | Manual Release Rod End | N/A | |
| 8 | Retaining Pin | N/A | |
| 9 | Manual release | 4180295 | Our Price: $20.00 |
| 10 | Gasket (Manifold) | 7099595 | Our Price: $20.00 |
| 11 | Parallel Pin | N/A | |
| 12 | Manifold | 499762 | Our Price: $114.00 |
| 13 | Copper Washer | 7039285 | Our Price: $3.00 |
| 14 | Banjo Bolt | 7110115 | Our Price: $9.00 |
| 15 | Lock Washer | N/A | |
| 16 | Allen Head Bolt | N/A | |
| 17 | O-Ring (With Part No. 18) | 7090150015 | Our Price: $2.00 |
| 18 | Brass By-Pass Cap (Break) | 4180265 | Our Price: $20.00 |
| 19 | O-Ring | 7090010015 | Our Price: $2.00 |
| 20 | Flange Bolt Stainless Steel | 7011355 | Our Price: $8.00 |
| 21 | Lock Washer | N/A | |
| 22 | Jack Counter Nut Brass Jam Nut | N/A | |
| 23 | Snap Ring | N/A | |
| 24 | Flange (Manifold Side) | 499760 | Our Price: $284.97 |
| 25 | Retract Tube | 7361365 | Our Price: $22.00 |
| 26 | Allen Head Screw | N/A | |
| 27 | O-Ring (With Part No. 28) | N/A | |
| 28 | Lock Valve | 4404085 | Our Price: $8.00 |
| 29 | Snap Ring | N/A | |
| 30 | O-Ring (Flange) | 7090490025 | Our Price: $3.00 |
| 31 | Cylinder | 7366135 | Our Price: $75.00 |
| 32 | Gasket (Cylinder) | 7099585 | Our Price: $5.00 |
| 33 | Ramping Piston | 7350275 | |
| 34 | O-Ring (Ramping Piston) | N/A | |
| 35 | Air Drain Valve | 7246025 | |
| 36 | Debris Cover | 7246025 | Our Price: $5.00 |
| 37 | O-Ring (Manual Release) | N/A | |
| 38 | Allen Head Bolt (Piston) | N/A | |
| 39 | Lock Washer | N/A | |
| 40 | RPiston (Red Internal) | 7094115 | Our Price: $13.00 |
| 41 | Piston Seal | 7092025 | Our Price: $15.00 |
| 42 | Piston | 7350275 | Our Price: $38.00 |
| 43 | Piston Seal (Inner) | 7049195 | Our Price: $23.00 |
| 44 | Vibration Dampener | 7119485 | Our Price: $3.00 |
| 45 | Lock Washer (Coated) | N/A | |
| 46 | O-Ring (Rack) | 7090380025 | Our Price: $3.00 |
| 47 | Rack | 7193205 | Our Price: $91.50 |
| 48 | Ram Body | 7160505 | Our Price: $84.00 |
| 49 | Flange (Non-Manifold) | 499761 | Our Price: $272.55 |
| 50 | Allen Head Screw | N/A | |
| 51 | Bracket (Pump to Drive) | 7224215 | Our Price: $6.00 |
| 52 | Gasket (Drive to Box) | 7099575 | Our Price: $8.00 |
| 53 | Self Tapping Screw | N/A | |
| 54 | Rack Protecting Cover | N/A | |
| 55 | O-Ring (Retracting Tube) | 7090665 | Our Price: $3.00 |
| 56 | Skin Pack (Mounting Hardware) | 3905515 | Our Price: $65.25 |
| 57 | Seal Kit | 2176* | Our Price: $131.25 |
| 58 | Monolec Oil (1 Qt.) | 6115 Qt+* | Our Price: $26.00 |
