| Scroll Down to View Exploded Parts View or Illustrated Parts Breakdown For Elite Swing Gate Operators Click on Image to Enlarge, after new window opens click on image again to enlarge more or you can download PDF File ELITE Parts Hercules ELITE Openers Hercules 8ft ---- ELITE Openers Hercules 10ft ----- ELITE Openers Hercules 12ft |
| ELITE Replacement Parts for your ELITE Operators - We Offer ELITE Factory Direct replacement parts and New Products for ELITE Systems, Gate Openers, Keypad Parts, Proximity and Multi-Tenant Access Control panels |
Welcome to: GATESNFENCES.COM
| Part Number Description for Elite Hercules Overhead Openers AH-110 CHAIN #41 (per 10' box) Q006 PC BOARD NUTS (SET) Q017 ELECTRONIC CONTROL BOARD Q027 MOTOR CAPACITOR Q029 LIMIT SWITCH Q067 CHASSIS Q068 ELECTRONIC BOX Q070 DRIVE SPROCKET Q072 GEAR BOX COVER Q074 COUPLING (3/4 x 5/8) Q075 LIMIT SWITCH BALL BEARING Q076 TURN BUCKLE Q077 TRACK (ONE PAIR 10') Q078 TROLLEY WHEEL SHAFT Q079 TROLLEY BODY Q080 DOLLY LATCH Q081 LIMIT SWITCH BOLT Q082 LIMIT SWITCH NUTS Q083 DOLLY WHEELS Q084 EMERGENCY KEY RELEASE Q085 DOLLY COVER Q086 RETAINING SPRING CLIP Q087 EMERGENCY PULLING RING Q088 GATE ARM Q090 PLASTIC PLUG Q091 IDLER SPROCKET Q092 RUBBER ISOLATOR Q092 RUBBER ISOLATOR Q093 IDLER SPROCKET COVER Q094 ARM BRACKET Q095 ARM BUSHING Q096 HEAD BRACKET Q097 OPERATOR MOUNTING BRACKET Q170 ELECTRONIC ACCESS PANEL Q248 GEAR REDUCER (40:1) Q250 1/2 HP ELECTRIC MOTOR Q400DHCT - OmniControl Board Post 2/07 Q404 HCT501130 - Elite Q404 - Omni Alarm Q410 Elite Q410 - Surge Suppressor Terminal Block Q620 HCT501130 - Elite Q620 - Motor Harness Omni |
| Q077-10 | Elite Hercules HCT501130 - Elite Q07710 - 10' Track, One Pair | Our Price: $225.82  |
| Q077-12 | Elite Hercules HCT501130 - Elite Q07712 - 12' Track, One Pair | Our Price: $336.87 |
| Q077-14 | Elite Hercules HCT501130 - Elite Q07714 - 14' Track, One Pair | Our Price: $480.98 |
| Q088 | Elite Hercules HCT501130 - Elite Q088 - Gate Arm | Our Price: $28.95 |
| 10-10203 | Elite Hercules HCT501130 - Elite 10-10203 - Curved Arm Assembly | Our Price: $14.95 |
| 10-10204 | Elite Hercules HCT501130 - Elite 10-10204 - Door Bracket | Our Price: $9.95 |
| 178B34 | Elite Hercules HCT501130 - Elite 178B34 - Straight Arm Assembly | Our Price: $21.95 |
| 1941240D | Elite Hercules HCT501130 - Elite 1941240D - Chain #41 (per 10' box) | Our Price: $19.95 |
| APBS1 | Elite Hercules HCT501130 - Elite APBS1 - Reset Button | Our Price: $21.95 |
| Q006 | Elite Hercules HCT501130 - Elite Q006 - PC Board Nuts (Set) | Our Price: $5.95 |
| Q027 | Elite Hercules HCT501130 - Elite Q027 - Motor Capacitor | Our Price: $63.99 |
| Q029 | Elite Hercules HCT501130 - Elite Q029 - Limit Switch (Sold Individually) | Our Price: $12.99 |
| Q067 | Elite Hercules HCT501130 - Elite Q067 - Chassis | Our Price: $99.95 |
| Q068 | Elite Hercules HCT501130 - Elite Q068 - Electronic Box | Our Price: $203.20 |
| Q070 | Elite Hercules HCT501130 - Elite Q070 - Drive Sprocket | Our Price: $15.95 |
| Q073 | Elite Hercules HCT501130 - Elite Q073 - Gear Box Cover Post 1/99 | Our Price: $29.95 |
| Q074 | Elite Hercules HCT501130 - Elite Q074 - Coupling (3/4 x 5/8) 3 pcs | Our Price: $51.66 |
| Q075 | Elite Hercules HCT501130 - Elite Q075 - Limit Switch Ball Bearing | Our Price: $9.95 |
| Q076 | Elite Hercules HCT501130 - Elite Q076 - Turn Buckle | Our Price: $25.95 |
| Q078 | Elite Hercules HCT501130 - Elite Q078 - Trolley Wheel Shaft | Our Price: $13.95 |
| Q079 | Elite Hercules HCT501130 - Elite Q079 - Trolley Body | Our Price: $49.95 |
| Q080 | Elite Hercules HCT501130 - Elite Q080 - Trolley Latch | Our Price: $29.95 |
| Q081 | Elite Hercules HCT501130 - Elite Q081 - Limit Switch Bolt | Our Price: $15.95 |
| Q082 | Elite Hercules HCT501130 - Elite Q082 - Limit Switch Nuts | Our Price: $15.95 |
| Q083 | Elite Hercules HCT501130 - Elite Q083 - Trolley Wheels | Our Price: $13.95 |
| Q084 | Elite Hercules HCT501130 - Elite Q084 - Emergency Key Release | Our Price: $13.95 |
| Q085 | Elite Hercules HCT501130 - Elite Q085 - Trolley Cover | Our Price: $69.95 |
| Q086 | Elite Hercules HCT501130 - Elite Q086 - Retaining Spring Clip | Our Price: $5.95 |
| Q087 | Elite Hercules HCT501130 - Elite Q087 - Emergency Pulling Ring | Our Price: $5.95 |
| Q089 | Elite Hercules HCT501130 - Elite Q089 - Trolley Body Assembly | Our Price: $176.73 |
| Q090 | Elite Hercules HCT501130 - Elite Q090 - Plastic Plug | Our Price: $5.95 |
| Q091 | Elite Hercules HCT501130 - Elite Q091 - Idler Sprocket | Our Price: $27.95 |
| Q092 | Elite Hercules HCT501130 - Elite Q092 - Rubber Isolator | Our Price: $19.95 |
| Q093 | Elite Hercules HCT501130 - Elite Q093 - Idler Sprocket Cover | Our Price: $17.95 |
| Q094 | Elite Hercules HCT501130 - Elite Q094 - Arm Bracket | Our Price: $13.95 |
| Q095 | Elite Hercules HCT501130 - Elite Q095 - Arm Bushing | Our Price: $13.95 |
| Q096 | Elite Hercules HCT501130 - Elite Q096 - Header Bracket | Our Price: $14.95 |
| Q097 | Elite Hercules HCT501130 - Elite Q097 - Mounting Plate | Our Price: $23.95 |
| Q118 | Elite Hercules HCT501130 - Elite Q118 - Key for Access Door/Hercules | Our Price: $9.95 |
| Q170 | Elite Hercules HCT501130 - Elite Q170 - Electronic Box Cover (Black) | Our Price: $45.95 |
Q200 |
Elite Hercules HCT501130 - Elite Q200 - Chain Coupling/Release | Our Price: $22.95 |
| Q248 | Elite Hercules HCT501130 - Elite Q248 - Gear Reducer (40:1) Post 2/99 | Our Price: $179.76 |
| Q250 | Elite Hercules HCT501130 - Elite Q250 - 1/2 HP Electric Motor Post 2/99 | Our Price: $283.45 |
| Q400DHCT | Elite Hercules HCT501130 - Elite Q400DHCT - OmniControl Board Post 2/07 | Our Price: $259.00 |
| Q404 | Elite Hercules HCT501130 - Elite Q404 - Omni Alarm | Our Price: $19.95 |
| Q410 | Elite Hercules HCT501130 - Elite Q410 - Surge Suppressor Terminal Block | Our Price: $59.95 |
| Q620 | Elite Hercules HCT501130 - Elite Q620 - Motor Harness Omni | Our Price: $16.95 |
