|DoorKing 1812 Single Family Intercom System
The model 1812 is a unique telephone intercom system that allows homeowners to use their telephone as an intercom to
speak to a guest at a front door or gate without the necessity to pay for an additional telephone line at their home. With
its "intercom mode" programming feature, the 1812 can also be connected to a PBX or KSU type system, making it ideal
for small businesses to control access through a single door or gate. Visitors are easily identified by voice
communication and can be granted or denied access directly from a touch-tone telephone. The 1812 is available in both
surface and flush mount designs and includes the DKS auto-programming software for Windows, allowing homeowners to
program the system right from their home computer.
The 1812 is available in three distinct styles:
Surface, flush or wall mount - specify which.
Stainless steel or gold plated housing (surface mount only).
Gold plated faceplate - Flush or surface mount units only
Unique telephone communication system allows homeowners to use their telephone as an intercom to speak to a guest
at a front door or gate, and to control access to their property.
Unit can be programmed from the homeowners PC with DoorKing’s Windows compatible Auto-Programming software.
Unit connects directly to the homeowners existing telephone line. No additional monthly expense for a second telephone
Built in call waiting assures that incoming calls or guest calls are not missed.
Two internal relays allow the system to control a main entry gate plus a pedestrian access gate.
Calls from the access system are identified with a double ring while regular calls use the standard single long ring.
Homeowners know instantly if a call is coming from their door or gate
Homeowners grant their guest access by pressing 9 on their telephone, or they can deny access by simply hanging up
Windows compatible auto programming software allows homeowners to program the system from their PC
Built-in clock / calendar provides the following time related functions:
1. Do-not-disturb time zone.
2. Four hold-open time zones.
3. Entry code time zones.
4.Call forwarding time zone.
5.Flash entry code.
Unit can be programmed to work with PBX and KSU phone systems.
Optional slave keypad can be added for remote entry code activation of door or gate. Order part number 1812-082.
Distinctive double ring identifies visitor calls from
3 preprogrammed call out telephone numbers.
"Do Not Disturb" time zone.
Hold open time zones.
Built-in time clock.
Entry code time zones.
"Flash" entry code.
LED lighted keypad.
2 relays for door/gate control.
Connects in series with the residential phone line. By-pass
Stores up to 3 call forwarding numbers.
Full duplex commnication.
50, 4-digit entry codes.
24 VAC, 20 VA (250 ma) power transformer provided.
FCC (US): DUF6VT-12874-OT-0
DOC (CAN): 1736 4507 A
Complies with UL 294; ETL Listed.
Surface mount dimensions: 6.25"H x 10"W x 5.25"D.
Flush mount dimensions: 9.25"H x 12"W x 4.5"D.
Wall mount dimensions: 7.325"H x 10.75"W x 3.5"D
|ACCESSORIES AVAILABLE FOR THIS MODEL
Heater kit (recommended when temperatures routinely fall below 10F
Auxiliary keypad for entry codes.
|Step One - Select A Style
|Step Two - Select Select Housing Option
|Accessories for 1812 Telephone Intercom System
|For additional information about the units scroll down for features and specification
Wireless Package for 1812 Systems
Ideal for single family homes and multi-unit complexes, the DKS wireless adapter reaches up to 1000 feet – no wires, no
trenching. Complete Plug-and-Play functionality. DKS Wireless Kits work with all 1812 models, just connect the router and
phone to the wireless adapter, connect to power... and you're ready to go!
Wireless Voice - Use your telephone to answer and grant/deny access to guests and visitors at a front door or gate.
Wireless Data - Connect to your computer for full programming and access controls/tracking.
Wireless Video - Place a camera anywhere around the door/gate, and view activity from your computer, smart device, or
ip addressable television.
Connect to a 2-line phone system, or to a separate cordless phone set.
Full duplex - talk simultaneously.
The call button from the 1812 will ring the phone, and the homeowner can speak with the visitor and grant/deny access
from the handset
1812 Classic and PLUS - Wireless full-duplex voice communication only. No computer programming on these models.
1812 AccessPLUS - Wireless full-duplex voice communication
and connects to your home computer network for programming.
PC programmable 1812 Access Plus.
Data connection to your home computer or laptop wirelessly.
Wireless system can also be used with DKS 1830 series with full programming capabilities (no voice on these systems).
An IP camera for video can be added to the wireless adapter system.
Video is transmitted over the wireless network.
Requires an ethernet switch at the remote location.
