One of the nation's foremost manufacturers of commercial and residential gate and door operating systems, OSCO provides quality automatic openers for the fencing, parking, ornamental iron and garage door industries.

ELECTRICAL FEATURES: Inherent entrapment sensing system featuring dual multi-turn precision potentiometers for accurate adjustment and enhanced safety Continuous tone entrapment alarm with reset button Integrated warning beeper during gate movement 15 diagnostic LEDs on board for ease of setup and troubleshooting Selectable pre-start alarm with provision for ADA compliant visual prestart and run alarm AC and DC power available for access control accessories Integrated maximum run and auto close timer (0-124 sec) Built-in master/slave capability using 3-wire shielded cable MODEL SWD EXCLUSIVE FEATURES: Full DC powered operator with built in battery backup Continuous duty 1/2 HP DC permanent magnet motor Powered by 115V or 24VDC supply Seamless transition to battery backup mode when AC power fails Selectable fail-safe or fail-secure modes of operation Solar power capable MECHANICAL FEATURES: Heavy duty zinc plated steel chassis Sleek and sturdy UV-stabilized polyethylene cover Universal pad mount standard - optional post mount kit available

3708 N.W. 82nd Street Miami  Florida  33147    305-696-0419    Fax: 305-696-0419

For Replacement Electronic Main Control Boards for must brands of gate openers Click Here

Business Directories Garden Garden Decor Home Home Security Home-improvements Hosting Informative Real-Estate Security Suppliers

Solid State Control Circuitry All SW Series operators utilize a common UL325/UL991 compliant 24VDC control board Fully featured board for complete access control, security and entrapment protection Polyethylene Cover The sleek and sturdy lockable cover is available in black, tan or granite with a lockable steel access door Heavy Duty Components Gear reducer and pillow block bearing provides smooth, reliable and quiet power transmission High starting torque - heavy duty PSC motors Standard Convenience Features Exterior reset button Power on/off button Accessory power outlet on 115V operators 3-button station Master/slave compatible - LH/RH selectable Easily accessible control box and limit switches Quick disconnect crank assembly Electrical/power disconnect Accepts all accessories Footprint 18.31" x 22.64"

Model	HP	Voltage (Single Phase)	Drive Type	Maximum Gate Length	Maximum Gate Weight	Gate Speed	Maximum Cycles	Shipping Weight
SWC-1	1	115 or 230V	crank	19ft	1000 lbs	11-14	Continuous	155lb
SWC-2	1/2	115 or 230V	crank	17ft	600 lbs	11-14	Continuous	155lb
SWD-211	1/2	115V/24VDC solar optional	crank	18ft	700 lbs	11-14	30/hour	155lb
SWR-211	1/2	115	crank	15 ft	500 lbs	11-14	150/day	155lb
SWR-221	1/2	230V	crank	15 ft	500 lbs	11-14	150/day	155lb
